motorola / Bipolar / mje1802d

Rating

Symbol

Value

Unit

Collector±Emitter Sustaining Voltage

VCEO

450

Vdc

Collector±Base Breakdown Voltage

VCBO

1000

Vdc

Collector±Emitter Breakdown Voltage

VCES

1000

Vdc

Emitter±Base Voltage

VEBO

12

Vdc

Collector Current Ð Continuous

IC

2

Adc

Ð Peak (1)

ICM

5

Base Current Ð Continuous

IB

1

Adc

Base Current Ð Peak (1)

IBM

2

*Total Device Dissipation @ TC = 25_C

PD

50

Watt

*Derate above 25°C

0.4

W/_C

Operating and Storage Temperature

TJ, Tstg

± 65 to 150

_C

Thermal Resistance Ð Junction to Case

RqJC

2.5

_C/W

Thermal Resistance Ð Junction to Ambient

RqJA

62.5

Maximum Lead Temperature for Soldering Purposes:

TL

260

_C

1/8″ from case for 5 seconds

(1) Pulse Test: Pulse Width = 5 ms, Duty Cycle ≤ 10%.

Characteristic

Symbol

Min

Typ

Max

Unit

OFF CHARACTERISTICS

Collector±Emitter Sustaining Voltage

VCEO(sus)

450

570

Vdc

(IC = 100 mA, L = 25 mH)

Collector Cutoff Current

ICEO

100

μAdc

(VCE = Rated VCEO, IB = 0)

Collector Cutoff Current (VCE = Rated VCES, VEB = 0)

@ TC = 25°C

ICES

100

μAdc

@ TC = 125°C

500

Collector Cutoff Current (VCE = 500 V, VEB = 0)

@ TC = 125°C

100

Emitter±Cutoff Current

IEBO

100

μAdc

(VEB = 10 Vdc, IC = 0)

ON CHARACTERISTICS

Base±Emitter Saturation Voltage

@ TC = 25°C

VBE(sat)

Vdc

(IC = 0.4 Adc, IB = 40 mAdc)

0.78

1

(IC = 1 Adc, IB = 0.2 Adc)

@ TC = 25°C

0.87

1.1

Collector±Emitter Saturation Voltage

@ TC = 25°C

VCE(sat)

Vdc

(IC = 0.4 Adc, IB = 40 mAdc)

0.36

0.6

@ TC = 125°C

0.5

1

(IC = 1 Adc, IB = 0.2 Adc)

@ TC = 25°C

0.4

0.75

@ TC = 125°C

0.65

1.2

DC Current Gain

@ TC = 25°C

hFE

Ð

(IC = 0.4 Adc, VCE = 1 Vdc)

14

25

@ TC = 125°C

8

15

(IC = 1 Adc, VCE = 1 Vdc)

@ TC = 25°C

6

10

@ TC = 125°C

4

6

DYNAMIC CHARACTERISTICS

Current Gain Bandwidth

fT

13

MHz

(IC = 0.5 Adc, VCE = 10 Vdc, f = 1 MHz)

Output Capacitance

Cob

50

100

pF

(VCB = 10 Vdc, IE = 0, f = 1 MHz)

Input Capacitance

Cib

340

500

pF

(VEB = 8 Vdc)

DIODE CHARACTERISTICS

Forward Diode Voltage

@ TC = 25°C

VEC

1.2

1.5

V

(IEC = 1 Adc)

(IEC = 0.2 Adc)

@ TC = 25°C

0.9

1.2

@ TC = 125°C

0.6

(IEC = 0.4 Adc)

@ TC = 25°C

1

1.3

@ TC = 125°C

0.6

Forward Recovery Time

tfr

540

ns

(IF = 0.2 Adc, di/dt = 10 A/μs)

@ TC = 25°C

(IF = 0.4 Adc, di/dt = 10 A/μs)

@ TC = 25°C

517

(IF = 1 Adc, di/dt = 10 A/μs)

@ TC = 25°C

480

2

Motorola Bipolar Power Transistor Device Data

Characteristic

Symbol

Min

Typ

Max

Unit

SWITCHING CHARACTERISTICS: Resistive Load (D.C. ≤ 10%, Pulse Width = 20 μs)

Turn±on Time

I

= 1 Adc, I

= 0.2 Adc

@ TC = 25°C

ton

100

150

ns

C

°

94

B1

@ TC = 125 C

IB2 = 0.5 Adc

Turn±off Time

@ TC = 25°C

toff

0.95

1.25

μs

VCC = 300 Vdc

@ TC = 125°C

1.5

SWITCHING CHARACTERISTICS: Inductive Load (Vclamp = 300 V, VCC = 15 V, L = 200 μH)

Fall Time

@ TC = 25°C

tf

130

175

ns

IC = 0.4 Adc

@ TC = 125°C

120

Storage Time

@ TC = 25°C

ts

0.55

0.65

μs

IB1 = 40 mAdc

@ TC = 125°C

0.7

IB2 = 0.2 Adc

Crossover Time

@ TC = 25°C

tc

110

175

ns

@ TC = 125°C

100

Fall Time

@ TC = 25°C

tf

130

175

ns

IC = 0.8 Adc

@ TC = 125°C

140

Storage Time

@ TC = 25°C

ts

2.1

2.4

μs

IB1 = 160 mAdc

@ TC = 125°C

3

IB2 = 160 mAdc

Crossover Time

@ TC = 25°C

tc

275

350

ns

@ TC = 125°C

350

Fall Time

@ TC = 25°C

tf

100

150

ns

IC = 1 Adc

@ TC = 125°C

100

Storage Time

@ TC = 25°C

ts

1.05

1.2

μs

IB1 = 0.2 Adc

@ TC = 125°C

1.45

IB2 = 0.5 Adc

Crossover Time

@ TC = 25°C

tc

100

150

ns

@ TC = 125°C

115

DYNAMIC SATURATION VOLTAGE

Dynamic Saturation

IC = 0.4 Adc

@ 1 μs

@ TC = 25°C

VCE(dsat)

7.4

V

IB1 = 40 mA

Voltage:

@ 3 μs

@ TC = 25°C

2.5

Determined 1 μs and

VCC = 300 V

3 μs respectively after

IC = 1 Adc

@ 1 μs

@ TC = 25°C

11.7

rising IB1 reaches

IB1 = 0.2 A

90% of final I

μ

°

1.3

B1

V

CC

= 300 V

@ 3 s

@ TC = 25 C

Motorola Bipolar Power Transistor Device Data

3
