MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document by TIP3055/D
Complementary Silicon Power
Transistors
. . . designed for general±purpose switching and amplifier applications.
•DC Current Gain Ð h FE = 20±70 @ IC = 4.0 Adc
•Collector±Emitter Saturation Voltage Ð V CE(sat) = 1.1 Vdc (Max) @ IC = 4.0 Adc
•Excellent Safe Operating Area
MAXIMUM RATINGS
Rating |
Symbol |
Value |
Unit |
|
|
|
|
Collector±Emitter Voltage |
VCEO |
60 |
Vdc |
Collector±Emitter Voltage |
VCER |
70 |
Vdc |
Collector±Base Voltage |
VCB |
100 |
Vdc |
Emitter±Base Voltage |
VEB |
7.0 |
Vdc |
Collector Current Ð Continuous |
IC |
1 5 |
Adc |
Base Current |
IB |
7.0 |
Adc |
Total Power Dissipation @ TC = 25_C |
PD |
90 |
Watts |
Derate above 25_C |
|
0.72 |
W/_C |
|
|
|
|
Operating and Storage Junction |
TJ, Tstg |
± 65 to +150 |
_C |
Temperature Range |
|
|
|
|
|
|
|
THERMAL CHARACTERISTICS
Characteristic |
Symbol |
Max |
Unit |
|
|
|
|
Thermal Resistance, Junction to Case |
RθJC |
1.39 |
_C/W |
Thermal Resistance, Junction to Ambient |
RθJA |
35.7 |
_C/W |
NPN
TIP3055
PNP
TIP2955
15 AMPERE
POWER TRANSISTORS COMPLEMENTARY SILICON
60 VOLTS
90 WATTS
CASE 340D±01
|
1000 |
|
|
|
|
|
|
|
|
|
|
GAIN |
|
|
|
|
|
|
VCE = 4.0 V |
|
|
|
|
|
|
|
|
|
|
TJ = 25°C |
|
|
|
||
CURRENT |
100 |
|
|
|
|
|
|
|
TIP3055 |
|
|
|
|
|
|
|
|
|
|
TIP2955 |
|
||
, DC |
|
|
|
|
|
|
|
|
|
|
|
FE |
|
|
|
|
|
|
|
|
|
|
|
h |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
0.2 |
|
0.5 |
0.7 |
|
|
3.0 |
5.0 |
|
|
|
0.1 |
0.3 |
1.0 |
2.0 |
7.0 |
10 |
|||||
IC, COLLECTOR CURRENT (AMP)
Figure 1. DC Current Gain
Motorola, Inc. 1995
TIP3055 |
TIP2955 |
|
|
|
|
|
|
ELECTRICAL CHARACTERISTICS (TC = 25_C unless otherwise noted) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Characteristic |
Symbol |
Min |
Max |
Unit |
|
|
|
|
|
|
|
|
OFF CHARACTERISTICS |
|
|
|
|
|
|
|
|
|
|
|
|
|
Collector±Emitter Sustaining Voltage (1) |
VCEO(sus) |
60 |
Ð |
Vdc |
|
|
(IC = 30 mAdc, IB = 0) |
|
|
|
|
|
|
Collector Cutoff Current |
ICER |
Ð |
1.0 |
mAdc |
|
|
(VCE = 70 Vdc, RBE = 100 Ohms) |
|
|
|
|
|
|
Collector Cutoff Current |
ICEO |
Ð |
0.7 |
mAdc |
|
|
(VCE = 30 Vdc, IB = 0) |
|
|
|
|
|
|
Collector Cutoff Current |
ICEV |
Ð |
5.0 |
mAdc |
|
|
(VCE = 100 Vdc, VBE(off) = 1.5 Vdc) |
|
|
|
|
|
|
Emitter Cutoff Current |
IEBO |
Ð |
5.0 |
mAdc |
|
|
(VBE = 7.0 Vdc, IC = 0) |
|
|
|
|
|
|
ON CHARACTERISTICS (1) |
|
|
|
|
|
|
|
|
|
|
|
|
|
DC Current Gain |
hFE |
|
|
Ð |
|
|
(IC = 4.0 Adc, VCE = 4.0 Vdc) |
|
20 |
70 |
|
|
|
(IC = 10 Adc, VCE = 4.0 Vdc) |
|
5.0 |
Ð |
|
|
|
Collector±Emitter Saturation Voltage |
VCE(sat) |
|
|
Vdc |
|
|
|
|
||||
|
(IC = 4.0 Adc, IB = 400 mAdc) |
|
Ð |
1.1 |
|
|
|
(IC = 10 Adc, IB = 3.3 Adc) |
|
Ð |
3.0 |
|
|
|
Base±Emitter On Voltage |
VBE(on) |
Ð |
1.8 |
Vdc |
|
|
(IC = 4.0 Adc, VCE = 4.0 Vdc) |
|
|
|
|
|
|
SECOND BREAKDOWN |
|
|
|
|
|
|
|
|
|
|
|
|
|
Second Breakdown Collector Current with Base Forward Biased |
Is/b |
3.0 |
Ð |
Adc |
|
|
(VCE = 30 Vdc, t = 1.0 s; Nonrepetitive) |
|
|
|
|
|
|
DYNAMIC CHARACTERISTICS |
|
|
|
|
|
|
|
|
|
|
|
|
|
Current Gain Ð Bandwidth Product |
fT |
2.5 |
Ð |
MHz |
|
|
(IC = 0.5 Adc, VCE = 10 Vdc, f = 1.0 MHz) |
|
|
|
|
|
|
Small±Signal Current Gain |
hfe |
15 |
Ð |
kHz |
|
|
(VCE = 4.0 Vdc, IC = 1.0 Adc, f = 1.0 kHz) |
|
|
|
|
|
|
(1) Pulse Test: Pulse Width = 300 μs, Duty Cycle v 2.0%. |
|
|
|
|
|
|
NOTE: For additional design curves, refer to electrical characteristics curves of 2N3055. |
|
|
|
|
|
|
100 |
|
|
|
|
|
|
|
(AMPS) |
50 |
|
|
|
|
|
|
|
30 |
|
|
|
|
|
|
|
|
20 |
|
|
|
|
|
300 μs |
||
CURRENT |
10 |
|
|
|
|
1.0 ms |
||
|
|
|
|
|
|
|||
5.0 |
|
|
|
dc |
|
|
|
|
|
|
|
|
|
10 ms |
|
||
3.0 |
|
|
|
|
|
|
||
COLLECTOR |
|
|
|
|
|
|
||
2.0 |
SECONDARY BREAKDOWN LIMIT |
|
|
|||||
|
|
|
||||||
1.0 |
BONDING WIRE LIMIT |
|
|
|
|
|||
0.5 |
THERMAL LIMIT @ TC = 25°C |
|
|
|
||||
, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C |
0.3 |
|
|
|
|
|
|
|
I |
TJ = 150°C |
|
|
|
|
|
||
|
0.2 |
|
|
|
|
|
||
|
0.1 |
|
|
|
|
|
|
|
|
1.0 |
2.0 |
4.0 |
6.0 |
10 |
20 |
40 |
60 |
|
|
VCE, COLLECTOR±EMITTER VOLTAGE (VOLTS) |
|
|||||
Figure 2. Maximum Rated Forward Bias
Safe Operating Area
There are two limitations on the power handling ability of a transistor: average junction temperature and second breakdown. Safe operating area curves indicate IC ± VCE limits of the transistor that must be observed for reliable operation; i.e., the transistor must not be subjected to greater dissipation than the curves indicate.
The data of Figure 2 is based on TC = 25_C; TJ(pk) is variable depending on power level. Second breakdown pulse
limits are valid for duty cycles to 10% but must be derated for temperature.
2 |
Motorola Bipolar Power Transistor Device Data |
TIP3055 TIP2955
PACKAGE DIMENSIONS
|
|
C |
NOTES: |
|
B |
Q |
E |
1. |
DIMENSIONING AND TOLERANCING PER ANSI |
|
Y14.5M, 1982. |
|||
|
|
|
2. |
CONTROLLING DIMENSION: MILLIMETER. |
|
|
|
|
|
MILLIMETERS |
INCHES |
|||
|
U |
|
4 |
DIM |
MIN |
MAX |
MIN |
MAX |
|
|
|
|
A |
A |
19.00 |
19.60 |
0.749 |
0.771 |
|
|
L |
|
B |
14.00 |
14.50 |
0.551 |
0.570 |
||
S |
|
|
C |
4.20 |
4.70 |
0.165 |
0.185 |
||
|
|
|
D |
1.00 |
1.30 |
0.040 |
0.051 |
||
|
|
|
|
||||||
|
1 |
2 |
3 |
E |
1.45 |
1.65 |
0.058 |
0.064 |
|
K |
G |
5.21 |
5.72 |
0.206 |
0.225 |
||||
|
|
|
|||||||
|
|
|
|
H |
2.60 |
3.00 |
0.103 |
0.118 |
|
|
|
|
|
J |
0.40 |
0.60 |
0.016 |
0.023 |
|
|
|
|
|
K |
28.50 |
32.00 |
1.123 |
1.259 |
|
|
|
|
|
L |
14.70 |
15.30 |
0.579 |
0.602 |
|
|
|
|
|
Q |
4.00 |
4.25 |
0.158 |
0.167 |
|
|
|
|
|
S |
17.50 |
18.10 |
0.689 |
0.712 |
|
|
|
|
|
U |
3.40 |
3.80 |
0.134 |
0.149 |
|
|
|
|
|
V |
1.50 |
2.00 |
0.060 |
0.078 |
|
D |
J |
STYLE 1: |
|
V |
H |
PIN 1. |
BASE |
G |
|
2. |
COLLECTOR |
|
3. |
EMITTER |
|
|
|
||
|
|
4. |
COLLECTOR |
CASE 340D±01
ISSUE A
Motorola Bipolar Power Transistor Device Data |
3 |
TIP3055 TIP2955
