3
Design
Wet-steam turbines for nuclear power plants are currently designed and produced by only a few manufacturers worldwide. Several former independent producers of nuclear turbines, including the British manufacturer GEC, which was formed from the merger of AEI and English Electric, French manufacturers Rateau, Alsacienne de Construction Mecanique (SACM), and Campaignie Electromecanique (CEM), and the German firm MAN—all merged to form GEC Alsthom. In turn, GEC Alsthom merged with ABB Kraftwerke AG, which had been formed from the merger of German-Swiss firms Brown Boveri and Escher-Wiss and Swedish manufacturer Stal-Laval, creating the international giant ABB-ALSTOM, presently named merely ALSTOM. In another spate of conglomeration, German firm Kraftwerke Union AG (Siemens/KWU) absorbed the British company NEI Parsons and the German AEG and then merged with Westinghouse to create another huge international concern, Siemens Power Generation (Siemens PG), which includes the U.S. subsidiary Siemens Westinghouse Power Corporation (SWPC).
Among other contemporary producers of wet-steam turbines for nuclear power plants are General Electric in the United States; a trio of Japanese manufacturers–Hitachi, Mitsubishi Heavy
www.EngineeringBooksPdf.com
102 Wet-Steam Turbines for Nuclear Power Plants
Industries (MHI), and Toshiba; Turboatom (also known as Kharkov Turbine Works, or KhTGZ) in Ukraine; Leningrad Metallic Works (LMZ) in Russia, and Škoda Energo (Skoda) in the Czech Republic. Combined, these companies have provided almost all of the steam turbines for every nuclear power plant in the world. In addition to the companies mentioned, Ansaldo Energia manufactured six turbines for Italian nuclear power plants with a total capacity of 3,530 MW; and Bharat Heavy Electricals Ltd. (BHEL) built a series of eight wet-steam turbines with individual capacities of about 230 MW for Indian nuclear power plants with PHWRs, under license from ALSTOM. Production of large-capacity wet-steam turbines is scheduled to commence in the near future at Donfang Steam Turbine Works and Shanghai Steam Turbine Co., Ltd. in China and at Doosan Heavy Industries & Construction Co. in South Korea.
As of January 2001, at the nuclear power plants of the IAEA’s member countries, there were in service at least 440 nuclear wetsteam turbines with individual output of more than 100 MW, not counting those installed in permanently or temporarily decommissioned power units.1
Some older nuclear power units were designed to be operated with two (or more) steam turbines fed with main steam in parallel. This explains a certain discrepancy between the above figure and the total number of nuclear power units according to the IAEA data given in chapter 1. This difference (between the number of nuclear wet-steam turbines and the total number of nuclear power units) also takes into account gas-cooled and fast breeder reactors working with superheated-steam turbines. The double-turbine scheme has been widely used at nuclear power units employing former Soviet reactors VVER-440 (31 power units in operation as of 2001, each one with two turbines with a rated output of about 220 MW), the first VVER-1000 (two 500-MW turbines), and RBMK-1000 and RBMK-1500 (14 power units in operation as of 2001, with turbines of rated output of 500 and 750 MW, respectively). In addition, this double-turbine scheme has been employed at some Western European and Asian nuclear power plants with PWR-, BWR-, and PHWR-type reactors.The use of this scheme was primarily intended to decrease the number of forced shutdowns in the case of wet-steam turbine failures, and also allow for the possibility
www.EngineeringBooksPdf.com
Design 103
of more efficient unloading of the units by shutting down one of the two (or more) turbines during power consumption ebbs at nights and on weekends. With regard to double-turbine units, the single capacity spectrum for the wet-steam turbines presented in Table 3–1 looks more logical. Even though the single capacities of nuclear power units are commonly given as net values, as applied to steam turbines it seems more representative to cite the gross capacity data.
Table 3–1. Distribution of wet-steam turbines by gross individual capacity (as of 2001)
Gross Capacity |
|
|
|
Number of Turbines |
|
|
|
|
(MW) |
|
|
|
|
|
|
|
|
|
U.S. |
France |
Japan |
Russia |
Germany |
Korea |
Others |
Total |
100—200 |
|
|
|
|
|
|
2 |
2 |
200—400 |
|
|
2 |
12 |
1 |
1 |
66 |
82 |
400—600 |
8 |
|
12 |
24 |
|
1 |
22 |
67 |
600—800 |
8 |
|
4 |
|
1 |
4 |
20 |
37 |
800—1,000 |
35 |
34 |
11 |
|
4 |
8 |
22 |
114 |
1,000—1,200 |
31 |
– |
21 |
6 |
|
2 |
16 |
76 |
1,200—1,400 |
22 |
20 |
2 |
|
7 |
|
1 |
52 |
1,400—1,600 |
|
4 |
|
|
6 |
|
|
10 |
Total |
104 |
58 |
52 |
42 |
19 |
16 |
144 |
440 |
Turbines with rated outputs between 200 and 600 MW, which amount to a significant portion of “nuclear” wet-steam turbines, including some of the double-turbine units mentioned previously, are generally referred to as being of moderate capacity.They are especially attractive for modest-sized and developing countries, as well as for relatively autonomous power systems. For industrially developed countries with highly developed power generation grids, larger power units (and turbines) are more attractive, with single capacity of about 1,000 MW or more. Due to larger capital expenditures and lower fuel costs, nuclear power generation costs depend to a greater degree on the installed capacity as compared with fossil fuel plants. Thus, an
www.EngineeringBooksPdf.com
104 Wet-Steam Turbines for Nuclear Power Plants
increase in capacity from 580 MW to 1,160 MW for a coal-fired plant was determined to decrease its power generation cost by about 8%, whereas the corresponding reduction for nuclear power plants with BWRs was approximately 30%. 2
Along with a trend toward increasing the single capacity of nuclear power units in the upper-end range of 1,300–1,700 MW and perhaps more in the future, many countries still have a demand for nuclear power plants with units of a moderate and relatively low single capacity. 3 This is due to constrained investment capital and limited power grid capacities. In recent years, many nuclear power projects featuring medium-sized reactors have begun development, and they will need wet-steam turbines of a corresponding capacity. There should be a high degree of freedom in the design of these units in order to match diverse investment capacities and customer needs. When the nuclear power plant output is relatively small, the benefits of improved thermal efficiency become somewhat less noticeable, and for this reason the emphasis is placed on decreasing civil engineering expenditures and simplifying the equipment design and operation rather than raising efficiency.As for simplifying the turbine design, this can first require reducing the number of LP flows and cylinders, and the use of less expensive material than titanium in the last stage blades (LSB). On the other hand, the use of longer titanium LSBs can result in reducing a number of the LP cylinders, and in this case, can adequately pay for itself.
General Design Features of
Wet-Steam Turbines
Influence of single capacity and rotation speed on turbine design
As distinct from some steam turbines for fossil fuel power plants, all wet-steam turbines for nuclear power plants, up to those of the largest individual capacity, are designed single-shaft, or tandemcompound (TC).This is mainly explained by the fact that both the HP and LP sections of wet-steam turbines work with wet steam, and their
