LM3S6965 Microcontroller
Register 27: Software Reset Control 0 (SRCR0), offset 0x040
Writes to this register are masked by the bits in the Device Capabilities 1 (DC1) register.
Software Reset Control 0 (SRCR0)
Base 0x400F.E000
Offset 0x040
Type R/W, reset 0x00000000
|
31 |
30 |
29 |
28 |
27 |
26 |
25 |
24 |
23 |
22 |
21 |
20 |
19 |
18 |
17 |
16 |
|
|
|
|
|
|
reserved |
|
|
|
|
|
PWM |
|
reserved |
|
ADC |
Type |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
R/W |
RO |
RO |
RO |
R/W |
Reset |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
15 |
14 |
13 |
12 |
11 |
10 |
9 |
8 |
7 |
6 |
5 |
4 |
3 |
2 |
1 |
0 |
|
|
|
|
|
reserved |
|
|
|
|
HIB |
reserved |
WDT |
|
reserved |
|
|
Type |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
R/W |
RO |
RO |
R/W |
RO |
RO |
RO |
Reset |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
Bit/Field |
Name |
Type |
Reset |
Description |
31:21 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
20 |
PWM |
R/W |
0 |
PWM Reset Control |
|
|
|
|
Reset control for PWM module. |
19:17 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
16 |
ADC |
R/W |
0 |
ADC0 Reset Control |
|
|
|
|
Reset control for SAR ADC module 0. |
15:7 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
6 |
HIB |
R/W |
0 |
HIB Reset Control |
|
|
|
|
Reset control for the Hibernation module. |
5:4 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
3 |
WDT |
R/W |
0 |
WDT Reset Control |
|
|
|
|
Reset control for Watchdog unit. |
2:0 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
November 16, 2008 |
127 |
Preliminary
System Control
Register 28: Software Reset Control 1 (SRCR1), offset 0x044
Writes to this register are masked by the bits in the Device Capabilities 2 (DC2) register.
Software Reset Control 1 (SRCR1)
Base 0x400F.E000
Offset 0x044
Type R/W, reset 0x00000000
|
31 |
30 |
29 |
28 |
27 |
26 |
25 |
24 |
23 |
22 |
21 |
20 |
19 |
18 |
17 |
16 |
|
|
|
reserved |
|
|
COMP1 |
COMP0 |
|
reserved |
|
TIMER3 |
TIMER2 |
TIMER1 |
TIMER0 |
||
Type |
RO |
RO |
RO |
RO |
RO |
RO |
R/W |
R/W |
RO |
RO |
RO |
RO |
R/W |
R/W |
R/W |
R/W |
Reset |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
15 |
14 |
13 |
12 |
11 |
10 |
9 |
8 |
7 |
6 |
5 |
4 |
3 |
2 |
1 |
0 |
|
reserved |
I2C1 |
reserved |
I2C0 |
reserved |
QEI1 |
QEI0 |
|
reserved |
|
SSI0 |
reserved |
UART2 |
UART1 |
UART0 |
|
Type |
RO |
R/W |
RO |
R/W |
RO |
RO |
R/W |
R/W |
RO |
RO |
RO |
R/W |
RO |
R/W |
R/W |
R/W |
Reset |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
Bit/Field |
Name |
Type |
Reset |
Description |
31:26 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
25 |
COMP1 |
R/W |
0 |
Analog Comp 1 Reset Control |
|
|
|
|
Reset control for analog comparator 1. |
24 |
COMP0 |
R/W |
0 |
Analog Comp 0 Reset Control |
|
|
|
|
Reset control for analog comparator 0. |
23:20 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
19 |
TIMER3 |
R/W |
0 |
Timer 3 Reset Control |
|
|
|
|
Reset control for General-Purpose Timer module 3. |
18 |
TIMER2 |
R/W |
0 |
Timer 2 Reset Control |
|
|
|
|
Reset control for General-Purpose Timer module 2. |
17 |
TIMER1 |
R/W |
0 |
Timer 1 Reset Control |
|
|
|
|
Reset control for General-Purpose Timer module 1. |
16 |
TIMER0 |
R/W |
0 |
Timer 0 Reset Control |
|
|
|
|
Reset control for General-Purpose Timer module 0. |
15 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
14 |
I2C1 |
R/W |
0 |
I2C1 Reset Control |
|
|
|
|
Reset control for I2C unit 1. |
13 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
128 |
November 16, 2008 |
Preliminary
LM3S6965 Microcontroller
Bit/Field |
Name |
Type |
Reset |
Description |
12 |
I2C0 |
R/W |
0 |
I2C0 Reset Control |
|
|
|
|
Reset control for I2C unit 0. |
11:10 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
9 |
QEI1 |
R/W |
0 |
QEI1 Reset Control |
|
|
|
|
Reset control for QEI unit 1. |
8 |
QEI0 |
R/W |
0 |
QEI0 Reset Control |
|
|
|
|
Reset control for QEI unit 0. |
7:5 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
4 |
SSI0 |
R/W |
0 |
SSI0 Reset Control |
|
|
|
|
Reset control for SSI unit 0. |
3 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
2 |
UART2 |
R/W |
0 |
UART2 Reset Control |
|
|
|
|
Reset control for UART unit 2. |
1 |
UART1 |
R/W |
0 |
UART1 Reset Control |
|
|
|
|
Reset control for UART unit 1. |
0 |
UART0 |
R/W |
0 |
UART0 Reset Control |
|
|
|
|
Reset control for UART unit 0. |
November 16, 2008 |
129 |
Preliminary
System Control
Register 29: Software Reset Control 2 (SRCR2), offset 0x048
Writes to this register are masked by the bits in the Device Capabilities 4 (DC4) register.
Software Reset Control 2 (SRCR2)
Base 0x400F.E000
Offset 0x048
Type R/W, reset 0x00000000
|
31 |
30 |
29 |
28 |
27 |
26 |
25 |
24 |
23 |
22 |
21 |
20 |
19 |
18 |
17 |
16 |
|
reserved |
EPHY0 |
reserved |
EMAC0 |
|
|
|
|
|
reserved |
|
|
|
|
|
|
Type |
RO |
R/W |
RO |
R/W |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
Reset |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
|
15 |
14 |
13 |
12 |
11 |
10 |
9 |
8 |
7 |
6 |
5 |
4 |
3 |
2 |
1 |
0 |
|
|
|
|
|
reserved |
|
|
|
|
GPIOG |
GPIOF |
GPIOE |
GPIOD |
GPIOC |
GPIOB |
GPIOA |
Type |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
RO |
R/W |
R/W |
R/W |
R/W |
R/W |
R/W |
R/W |
Reset |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
Bit/Field |
Name |
Type |
Reset |
Description |
31 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
30 |
EPHY0 |
R/W |
0 |
PHY0 Reset Control |
|
|
|
|
Reset control for Ethernet PHY unit 0. |
29 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
28 |
EMAC0 |
R/W |
0 |
MAC0 Reset Control |
|
|
|
|
Reset control for Ethernet MAC unit 0. |
27:7 |
reserved |
RO |
0 |
Software should not rely on the value of a reserved bit. To provide |
|
|
|
|
compatibility with future products, the value of a reserved bit should be |
|
|
|
|
preserved across a read-modify-write operation. |
6 |
GPIOG |
R/W |
0 |
Port G Reset Control |
|
|
|
|
Reset control for GPIO Port G. |
5 |
GPIOF |
R/W |
0 |
Port F Reset Control |
|
|
|
|
Reset control for GPIO Port F. |
4 |
GPIOE |
R/W |
0 |
Port E Reset Control |
|
|
|
|
Reset control for GPIO Port E. |
3 |
GPIOD |
R/W |
0 |
Port D Reset Control |
|
|
|
|
Reset control for GPIO Port D. |
2 |
GPIOC |
R/W |
0 |
Port C Reset Control |
|
|
|
|
Reset control for GPIO Port C. |
1 |
GPIOB |
R/W |
0 |
Port B Reset Control |
|
|
|
|
Reset control for GPIO Port B. |
130 |
November 16, 2008 |
Preliminary
LM3S6965 Microcontroller
Bit/Field |
Name |
Type |
Reset |
Description |
0 |
GPIOA |
R/W |
0 |
Port A Reset Control |
|
|
|
|
Reset control for GPIO Port A. |
November 16, 2008 |
131 |
Preliminary
