DICOM PS3.16 2020a - Content Mapping Resource​ Page 591​

CID 3240 Electrophysiology Measurement Functions and Techniques​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.53​

Table CID 3240. Electrophysiology Measurement Functions and Techniques​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

109006​

Differential signal​

DCM​

109007​

His bundle electrogram​

DCM​

109008​

Monopole signal​

DCM​

109009​

Pacing (electrical) stimulus, voltage​

DCM​

109010​

Radio frequency ablation, power​

DCM​

109011​

Voltage measurement by basket catheter​

DCM​

109012​

Voltage measurement by mapping catheter​

DCM​

109013​

Voltage measurement​

CID 3241 Hemodynamic Measurement Techniques​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20160314​

UID:​

1.2.840.10008.6.1.54​

Table CID 3241. Hemodynamic Measurement Techniques​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique​

Designator​







ID​

SCT​

128580001​

Averaged hemodynamic​

PA-50038​

C1266842​





measurement method​





SCT​

128577002​

Composite hemodynamic​

PA-50035​

C1266839​





measurement method​





SCT​

128576006​

Computed hemodynamic​

PA-50034​

C1266838​





measurement method​





SCT​

133910006​

Conductance catheter method​

PA-5003B​

C1297901​

SCT​

133911005​

Doppler catheter method​

PA-5003C​

C1297902​

SCT​

128573003​

Dual catheter method​

PA-50031​

C1266836​

SCT​

128581002​

Fluid filled catheter method​

PA-50039​

C1266843​

SCT​

133912003​

Fiberoptic catheter method​

PA-5003D​

C1297903​

SCT​

133913008​

Hall catheter method​

PA-5003E​

C1297904​

SCT​

128575005​

Pullback method​

PA-50033​

C1276411​

SCT​

128448001​

Pulmonary capillary wedge method​

G-DB26​

C1264741​

SCT​

128578007​

Static catheter method​

PA-50036​

C1266840​

SCT​

133914002​

Thermistor catheter method​

PA-5003F​

C1297905​

SCT​

128582009​

Tip manometer method​

PA-5003A​

C1266844​

SCT​

128579004​

Wedge method​

PA-50037​

C1266841​

- Standard -​

Page 592​ DICOM PS3.16 2020a - Content Mapping Resource​

CID 3250 Catheterization Procedure Phase​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20160314​

UID:​

1.2.840.10008.6.1.55​

Table CID 3250. Catheterization Procedure Phase​

CodingScheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLSConceptUnique​

Designator​







ID​

SCT​

128961006​

Cardiac catheterization bailout phase​

G-7299​

C1292438​

SCT​

128955008​

Cardiac catheterization baseline phase​

G-7293​

C1292432​

SCT​

128956009​

Cardiaccatheterizationimageacquisition​

G-7294​

C1292433​





phase​





SCT​

128957000​

Cardiac catheterization intervention​

G-7295​

C1292434​





phase​





SCT​

129083002​

Cardiac catheterization post contrast​

G-729B​

C1292440​





phase​





SCT​

128960007​

Cardiaccatheterizationpost-intervention​

G-7298​

C1292437​





phase​





SCT​

128958005​

Cardiac catheterization pre-intervention​

G-7296​

C1292435​





phase​





SCT​

373105002​

Cardiac catheterization test/challenge​

R-002E4​

C1300063​





phase​





SCT​

128959002​

Cardiac catheterization therapy phase​

G-7297​

C1292436​

SCT​

128952006​

Catheterizationofbothleftandrightheart​

P1-3160A​

C1293383​





with graft​





SCT​

128953001​

Catheterizationofbothleftandrightheart​

P1-3160B​

C1293384​





without graft​





SCT​

67629009​

Catheterization of left heart​

P1-31604​

C0189897​

SCT​

40403005​

Catheterization of right heart​

P1-31602​

C0189896​

SCT​

67338003​

Transseptal catheterization​

P1-31612​

C0189901​

SCT​

133882006​

Drug Infusion Challenge​

P2-71317​

C1297891​

SCT​

128967005​

Exercise challenge​

P2-71310​

C1293901​

SCT​

128975004​

Resting State​

F-01604​

C0679218​

CID 3254 Electrophysiology Procedure Phase​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.56​

Table CID 3254. Electrophysiology Procedure Phase​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLSConceptUnique​

Designator​







ID​

SCT​

129087001​

Atrial Effective Refractory Period,​

G-729D​

C0428938​





evaluation of​





SCT​

129090007​

CarotidSinusMassageprocedurephase​

G-7304​

C1292445​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 593​

Coding Scheme​

Code Value​

Code Meaning​



SNOMED-RT ID​ UMLSConceptUnique​

Designator​









ID​

SCT​

129092004​

Electrophysiology Mapping phase​



G-7406​

C1292447​

SCT​

129082007​

Electrophysiology procedure baseline​



G-729A​

C1292439​





phase​







SCT​

129093009​

Post-ablation phase​



G-7408​

C1292448​

SCT​

129091006​

Post-defibrillation procedure phase​



G-7305​

C1292446​

SCT​

129089003​

Radiofrequency Ablation procedure​



G-729F​

C1292442​





phase​







SCT​

129086005​

Sinus Node Recovery Time, evaluation​

G-729C​

C1292441​





of​







SCT​

129088006​

Ventricular Effective Refractory Period,​

G-729E​

C0428940​





evaluation of​







CID 3261 Stress Protocols​







Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​





Type:​

Extensible​







Version:​

20081027​







UID:​

1.2.840.10008.6.1.57​











Table CID 3261. Stress Protocols​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique​

Designator​









ID​

SCT​

129097005​

Balke protocol​



P2-7131C​

C0442712​

SCT​

129095002​

Bruce protocol​



P2-7131A​

C0442713​

SCT​

129098000​

Ellestad protocol​



P2-7131D​

C1276407​

SCT​

129096001​

Modified Bruce protocol​



P2-7131B​

C0442714​

SCT​

129102008​

Modified Naughton protocol​



P2-713A1​

C1293907​

SCT​

129101001​

Naughton protocol​



P2-713A0​

C0442715​

SCT​

129100000​

Pepper protocol​



P2-7131F​

C1276409​

SCT​

129099008​

Ramp protocol​



P2-7131E​

C1276408​

SCT​

46136006​

Exercise stress ECG test​



P2-31010​

C1304755​

SCT​

26046004​

StresstestusingBicycleErgometer​



P2-31102​

C0430459​

SCT​

424064009​

Pharmacologic Stress protocol​



P2-31107​

C1827946​

SCT​

422685009​

Dipyridamole Stress protocol​



P2-3110A​

C1827789​

SCT​

424444005​

Adenosine Stress protocol​



P2-31109​

C1827363​

SCT​

424225000​

Dobutamine Stress protocol​



P2-31108​

C1828348​

SCT​

428813002​

Pharmacologicandexercisestress​



P2-31011​

C1998158​





test​







SCT​

428685003​

Stress test using cardiac pacing​



P2-3110B​

C1997441​

CID 3262 ECG Patient State Values​







Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​





Type:​

Extensible​







Version:​

20020904​







UID:​

1.2.840.10008.6.1.58​







- Standard -​

Page 594​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 3262. ECG Patient State Values​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique ID​

Designator​







SCT​

128974000​

Baseline state​

SCT​

128976003​

Exercise state​

SCT​

128977007​

Post-exercise state​

SCT​

128975004​

Resting state​

SCT​

40199007​

Supine body position​

F-01602​

C1290922​

F-01606​

C1290923​

F-01608​

C1290924​

F-01604​

C0679218​

F-10340​

C0038846​

CID 3263 Electrode Placement Values​

This Context Group comprises the ECG lead placement system identifiers of ISO/IEEE 11073-10102. The terms included in the table​ below may not constitute the complete list; see the ISO/IEEE Standard.​

Note​

Codes reprinted by permission of IEEE, Copyright 2004 by IEEE. ISO/IEEE 11073-10102 available through http://​ standards.ieee.org/.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20080927​

UID:​

1.2.840.10008.6.1.59​

Table CID 3263. Electrode Placement Values​

Coding​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent Reference ID​

Scheme​





(Informative)​

Designator​







MDC​

10:11264​

Unspecified 12-lead system​

MDC_ECG_LDSYS_12LD_UNSPECIFIED​

MDC​

10:11265​ Standard12-leadpositions,electrodes​MDC_ECG_LDSYS_12LD_STD​





placed individually​



MDC​

10:11266​ Mason-Likarleadpositions,electrodes​MDC_ECG_LDSYS_12LD_MASON_LIKAR​





placed individually​



MDC​

10:11267​ Mason-Likar lead positions, V1-V6 in​MDC_ECG_LDSYS_12LD_VPAD​





electrode pad​



MDC​

10:11268​

12-lead electrode pad​

MDC_ECG_LDSYS_12LD_PAD​

MDC​

10:11269​ 12-lead derived from Frank XYZ leads​MDC_ECG_LDSYS_12LD_FROM_FRANK​

MDC​

10:11270​ 12-lead derived from non-standard​

MDC_ECG_LDSYS_12LD_NON_STANDARD​





leads​



MDC​

10:11271​ 12-lead for bicycle exercise testing,​

MDC_ECG_LDSYS_12LD_BICYCLE​





limb leads on back of patient​



MDC​

10:11272​ Standard 12-lead positions one​

MDC_ECG_LDSYS_12LD_RAISED_INTERCOSTAL​





intercostal space higher​



MDC​

10:11273​ Unspecified XYZ lead system​

MDC_ECG_LDSYS_XYZ_UNSPECIFIED​

MDC​

10:11274​ Frank XYZ lead system​

MDC_ECG_LDSYS_XYZ_FRANK​

MDC​

10:11275​ McFee-Parungao XYZ lead system​

MDC_ECG_LDSYS_XYZ_MCFEE_PARUNAGO​

MDC​

10:11276​ Cube XYZ lead system​

MDC_ECG_LDSYS_XYZ_CUBE​

MDC​

10:11277​ Bipolar uncorrected XYZ lead system​MDC_ECG_LDSYS_XYZ_BIPOLAR​

MDC​

10:11278​ Pseudo-orthogonal XYZ lead system​MDC_ECG_LDSYS_XYZ_PSEUDO_ORTH​

- Standard -​





DICOM PS3.16 2020a - Content Mapping Resource​

Page 595​

Coding​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent Reference ID​

Scheme​





(Informative)​



Designator​









MDC​

10:11279​

XYZ leads derived from standard​

MDC_ECG_LDSYS_XYZ_FROM_12LD​







12-lead​





MDC​

10:11280​

NEHB lead system​

MDC_ECG_LDSYS_3LD_NEHB​



MDC​

10:11281​

3-lead system, CC5-CM5-ML​

MDC_ECG_LDSYS_3LD_CC5_CM5_ML​



MDC​

10:11282​

3-lead system, CC5-CM5-CH5​

MDC_ECG_LDSYS_3LD_CM5_CC5_CH5​



MDC​

10:11283​ 12-leadfromFrankleadsXYZleadsby​MDC_ECG_LDSYS_12LD_FROM_DOWER​





Dower transformation​





MDC​

10:11284​ 12-lead from EASI leads (ES, AS, AI)​MDC_ECG_LDSYS_12LD_FROM_EASI​







by Dower/EASI transformation​





MDC​

10:11285​ 12-leadfromLimbLeads(I,II)andone​MDC_ECG_LDSYS_12LD_FROM_LIMB​







or more V leads​





MDC​

10:11286​

Standard 12-lead and XYZ​

MDC_ECG_LDSYS_12LD_STD_AND_XYZ​



MDC​

10:11287​

Standard 12-lead and NEHB​

MDC_ECG_LDSYS_12LD_STD_AND_NEHB​

MDC​

10:11288​ Standard 12-lead and CC5-CM5-ML​ MDC_ECG_LDSYS_12LD_STD_AND_CC5_CM5_ML​

MDC​

10:11289​ Standard 12-lead and CM5-CC5-CH5​MDC_ECG_LDSYS_12LD_STD_AND_CM5_CC5_CH5​

MDC​

10:11290​ Standard 12-lead with extra leads to​ MDC_ECG_LDSYS_12LD_STD_EXTD​







the right and/or left sides​





MDC​

10:11291​ Standard 12-lead extended to the right​MDC_ECG_LDSYS_12LD_STD_EXTD_RIGHT​





by V5R, V4R, V3R​





MDC​

10:11292​ Standard 12-lead extended to the left​MDC_ECG_LDSYS_12LD_STD_EXTD_LEFT​





by V7, V8, V9​





Note​

A prior version of this context group used codes from the SCP-ECG vocabulary.​

CID 3264 XYZ Electrode Placement Values (Retired)​

This Context Group is retired. See PS3.16-2009.​

CID 3271 Hemodynamic Physiological Challenges​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20100625​

UID:​

1.2.840.10008.6.1.61​

Table CID 3271. Hemodynamic Physiological Challenges​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLSConceptUniqueID​

Designator​









SCT​

133882006​

Drug infusion​

P2-71317​

C1297891​

SCT​

128967005​

Exercise challenge​

P2-71310​

C1293901​

SCT​

128965002​

Handgrip​

P2-71306​

C1293900​

SCT​

128963009​

Head up​

P2-71302​

C1293898​

SCT​

128969008​

Held inspiration​

P2-71314​

C1293904​

SCT​

128970009​

Held ventilation​

P2-71316​

C1293905​

SCT​

128964003​

Leg up​

P2-71304​

C1293899​

- Standard -​

Page 596​

DICOM PS3.16 2020a - Content Mapping Resource​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLSConceptUniqueID​

Designator​









SCT​

128966001​

Negativelowerbodypressure​

P2-71308​

C0024047​

SCT​

18590009​

Pacing​

P2-35000​

C0199640​

SCT​

128971008​

Post volume challenge​

P2-71318​

C1293906​

SCT​

128968000​

Vagal stimulation​

P2-71312​

C1293903​

SCT​

261039008​

Valsalva maneuver​

R-40928​

C0042293​

CID 3335 ECG Annotations​

This Context Group comprises the nomenclature of ISO/IEEE 11073-10102, limited to the hierarchies under Reference IDs​ MDC_ECG_WAVEC, MDC_ECG_WAVEP, MDC_ECG_BEAT, and MDC_ECG_NOISE.​

The base terms from those hierarchies are included in the table below for reference. Note that these base terms are pre-coordinated​ with a variety of concept discriminators, and the code values for those pre-coordinated terms are arithmetically derived from the code​ valuesofthebaseterms.Forthecompletecurrentlistoftermsanddiscriminatorvalues,seetheISO/IEEEStandard.Allpre-coordinated​ terms (annotation plus discriminators) within the identified hierarchies are part of this Context Group.​

Note​

1.​This Context Group is used in the Concept Name Code Sequence of the Waveform Annotation Sequence (0040,B020).​ See PS3.3.​

2.​A prior version of this context group used codes from the SCP-ECG coding system.​

3.​Codes reprinted by permission of IEEE, Copyright 2004 by IEEE. ISO/IEEE 11073-10102 available through http://​ standards.ieee.org/.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20130613​

UID:​

1.2.840.10008.6.1.62​

Table CID 3335. ECG Annotations​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent​

Designator​





Reference ID (Informative)​

MDC​

10:256​

P wave​

MDC_ECG_WAVC_PWAVE​

MDC​

10:320​

P' wave (second deflection in P wave)​

MDC_ECG_WAVC_PPWAVE​

MDC​

10:384​

P'' wave (third deflection in P wave)​

MDC_ECG_WAVC_PPPWAVE​

MDC​

10:448​

Q wave​

MDC_ECG_WAVC_QWAVE​

MDC​

10:512​

QS wave​

MDC_ECG_WAVC_QSWAVE​

MDC​

10:576​

R wave​

MDC_ECG_WAVC_RWAVE​

MDC​

10:640​

R' wave (second deflection in R Wave)​

MDC_ECG_WAVC_RRWAVE​

MDC​

10:704​

R'' wave (third deflection in R Wave)​

MDC_ECG_WAVC_RRRWAVE​

MDC​

10:768​

Notch​

MDC_ECG_WAVC_NOTCH​

MDC​

10:832​

S wave​

MDC_ECG_WAVC_SWAVE​

MDC​

10:896​

S' wave (second deflection in S Wave)​

MDC_ECG_WAVC_SSWAVE​

MDC​

10:960​

S'' wave (third deflection in S Wave)​

MDC_ECG_WAVC_SSSWAVE​

MDC​

10:1024​

T wave​

MDC_ECG_WAVC_TWAVE​

MDC​

10:1088​

T' wave (second deflection in T Wave)​

MDC_ECG_WAVC_TTWAVE​

MDC​

10:1152​

U wave​

MDC_ECG_WAVC_UWAVE​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 597​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent​

Designator​





Reference ID (Informative)​

MDC​

10:1216​

Delta wave​

MDC_ECG_WAVC_DELTA​



MDC​

10:1280​

Isoelectric region from global QRS onset​MDC_ECG_WAVC_IWAVE​







to specific lead onset​





MDC​

10:1344​

Isoelectric region from specific lead QRS​MDC_ECG_WAVC_KWAVE​







Offset to global offset​





MDC​

10:1408​

Osborne wave​

MDC_ECG_WAVC_JWAVE​



MDC​

10:1472​

Entire Beat (Pon to Toff, excluding U)​

MDC_ECG_WAVC_PQRSTWAVE​

MDC​

10:1536​

Entire Beat (Qon to Toff, excluding P and​MDC_ECG_WAVC_QRSTWAVE​





U)​





MDC​

10:1600​

Entire QRS (excluding P, T and U)​

MDC_ECG_WAVC_QRSWAVE​



MDC​

10:1664​

TU fused wave​

MDC_ECG_WAVC_TUWAVE​



MDC​

10:1728​

Ventricular flutter wave​

MDC_ECG_WAVC_VFLWAVE​



MDC​

10:1792​

Atrial flutter wave​

MDC_ECG_WAVC_AFLWAVE​



MDC​

10:1856​

Isoelectric point or segment​

MDC_ECG_WAVC_ISO​



MDC​

10:1920​

PR Segment​

MDC_ECG_WAVC_PRSEG​



MDC​

10:1984​

ST Segment​

MDC_ECG_WAVC_STSEG​



MDC​

10:2048​

J-point​

MDC_ECG_WAVC_STJ​



MDC​

10:2112​

ST measurement point​

MDC_ECG_WAVC_STM​



MDC​

10:2176​

Isolated QRS-like artifact​

MDC_ECG_WAVC_ARFCT​



MDC​

10:2240​

Calibration pulse (individual pulse)​

MDC_ECG_WAVC_CALP​



MDC​

10:2304​

ST change​

MDC_ECG_WAVC_STCH​



MDC​

10:2368​

T-wave change​

MDC_ECG_WAVC_TCH​



MDC​

10:2432​

Ventricular Activation Time​

MDC_ECG_WAVC_VAT​



MDC​

10:4096​

Antibradycardia pace spike​

MDC_ECG_WAVP_PACE​



MDC​

10:4352​

atrium Antibradycardia pace spike​

MDC_ECG_WAVP_PACE_ATR​



MDC​

10:4608​

right atrium Antibradycardia pace spike​ MDC_ECG_WAVP_PACE_ATR_R​

MDC​

10:4864​

left atrium Antibradycardia pace spike​

MDC_ECG_WAVP_PACE_ATR_L​

MDC​

10:5120​

ventricular Antibradycardia pace spike​

MDC_ECG_WAVP_PACE_V​



MDC​

10:5376​

right ventricle Antibradycardia pace spike​MDC_ECG_WAVP_PACE_V_R​



MDC​

10:5632​

left ventricle Antibradycardia pace spike​MDC_ECG_WAVP_PACE_V_L​



MDC​

10:5888​

transthoracic Antibradycardia pace spike​MDC_ECG_WAVP_PACE_EXT​



MDC​

10:6144​

Antitachycardia pace spike​

MDC_ECG_WAVP_ATPACE​



MDC​

10:6400​

atrium Antitachycardia pace spike​

MDC_ECG_WAVP_ATPACE_ATR​

MDC​

10:6656​

ventricle Antitachycardia pace spike​

MDC_ECG_WAVP_ATPACE_V​



MDC​

10:6912​

transthoracic Antitachycardia pace spike​MDC_ECG_WAVP_ATPACE_EXT​

MDC​

10:7168​

Cardioversion spike​

MDC_ECG_WAVP_CDVS​



MDC​

10:7424​

atrium Cardioversion spike​

MDC_ECG_WAVP_CDVS_ATR​

MDC​

10:7680​

ventricle Cardioversion spike​

MDC_ECG_WAVP_CDVS_V​



MDC​

10:7936​

transthoracic Cardioversion spike​

MDC_ECG_WAVP_CDVS_EXT​



MDC​

10:8192​

Defibrillation spike​

MDC_ECG_WAVP_DEFIB​



MDC​

10:8448​

atrium Defibrillation spike​

MDC_ECG_WAVP_DEFIB_ATR​

MDC​

10:8704​

ventricle Defibrillation spike​

MDC_ECG_WAVP_DEFIB_V​



- Standard -​

Page 598​

DICOM PS3.16 2020a - Content Mapping Resource​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent​

Designator​





Reference ID (Informative)​

MDC​

10:8960​

transthoracic Defibrillation spike​

MDC_ECG_WAVP_DEFIB_EXT​

MDC​

10:8192​

Heart beat​

MDC_ECG_BEAT​

MDC​

10:8208​

Normal beat (sinus beat, normal​

MDC_ECG_BEAT_NORMAL​





conduction)​



MDC​

10:8224​

Abnormal beat​

MDC_ECG_BEAT_ABNORMAL​

MDC​

10:8240​

Dominant beat​

MDC_ECG_BEAT_DOMINANT​

MDC​

10:8256​

Supraventricular premature contraction​ MDC_ECG_BEAT_SV_P_C​

MDC​

10:8272​

Atrial premature contraction (beat)​

MDC_ECG_BEAT_ATR_P_C​

MDC​

10:8288​

Junctional (nodal) premature contraction​MDC_ECG_BEAT_JUNC_P_C​

MDC​

10:8304​

Aberrated atrial premature beat (Ashman​MDC_ECG_BEAT_ATR_P_C_ABERR​





beat)​



MDC​

10:8320​

Non-conducted p-wave (blocked)​

MDC_ECG_BEAT_ATR_PWAVE_BLK​

MDC​

10:8336​

Ventricular premature contraction beat​

MDC_ECG_BEAT_V_P_C​

MDC​

10:8352​

Fusion of ventricular and normal beat​

MDC_ECG_BEAT_V_P_C_FUSION​

MDC​

10:8368​

R-on-T premature ventricular beat​

MDC_ECG_BEAT_V_P_C_RonT​

MDC​

10:8384​

Supraventricular escape beat​

MDC_ECG_BEAT_SV_ESC​

MDC​

10:8400​

Atrial escape beat​

MDC_ECG_BEAT_ATR_ESC​

MDC​

10:8416​

Junctional (nodal) escape beat​

MDC_ECG_BEAT_JUNC_ESC​

MDC​

10:8432​

Ventricular escape beat​

MDC_ECG_BEAT_V_ESC​

MDC​

10:8448​

Bundle branch block beat​

MDC_ECG_BEAT_BB_BLK​

MDC​

10:8464​

Left bundle branch block beat​

MDC_ECG_BEAT_LBB_BLK_COMP​

MDC​

10:8480​

Incomplete left bundle branch block beat​MDC_ECG_BEAT_LBB_BLK_INCOMP​

MDC​

10:8496​

Right bundle branch block beat​

MDC_ECG_BEAT_RBB_BLK_COMP​

MDC​

10:8512​

Incomplete right bundle branch block beat​MDC_ECG_BEAT_RBB_BLK_INCOMP​

MDC​

10:8528​

Left anterior fascicular block beat​

MDC_ECG_BEAT_BLK_ANT_L_HEMI​

MDC​

10:8544​

Left posterior fascicular block beat​

MDC_ECG_BEAT_BLK_POS_L_HEMI​

MDC​

10:8560​

bifascicular block beat​

MDC_ECG_BEAT_BLK_BIFASC​

MDC​

10:8576​

trifascicular block beat​

MDC_ECG_BEAT_BLK_TRIFASC​

MDC​

10:8592​

bilateral bundle-branch block beat​

MDC_ECG_BEAT_BLK_BILAT​

MDC​

10:8608​

intraventricular conduction disturbance​

MDC_ECG_BEAT_BLK_IVCD​

MDC​

10:8624​

pre-excitation​

MDC_ECG_BEAT_PREX​

MDC​

10:8640​

Wolf-Parkinson-White syndrome​

MDC_ECG_BEAT_WPW_UNK​

MDC​

10:8656​

Wolf-Parkinson type A​

MDC_ECG_BEAT_WPW_A​

MDC​

10:8672​

Wolf-Parkinson type B​

MDC_ECG_BEAT_WPW_B​

MDC​

10:8688​

Lown-Ganong-Levine syndrome​

MDC_ECG_BEAT_LGL​

MDC​

10:8704​

Paced beat​

MDC_ECG_BEAT_PACED​

MDC​

10:8720​

Pacemaker Fusion beat​

MDC_ECG_BEAT_PACED_FUS​

MDC​

10:8736​

Unclassifiable beat​

MDC_ECG_BEAT_UNKNOWN​

MDC​

10:8752​

Pacemaker Learning beat​

MDC_ECG_BEAT_LEARN​

MDC​

10:11200​

No Noise​

MDC_ECG_NOISE_CLEAN​

MDC​

10:11216​

Moderate Noise, beats can be detected​ MDC_ECG_NOISE_MODERATE​





but cannot be classified​



- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​



Page 599​

Coding Scheme​

Code Value​



Code Meaning​

ISO/IEEE 11073 MDC Equivalent​

Designator​









Reference ID (Informative)​

MDC​

10:11232​

Severe Noise, beats cannot be detected​MDC_ECG_NOISE_SEVERE​





or classified​







MDC​

10:11248​

No ECG signal is available​

MDC_ECG_NOISE_NOSIGNAL​

Note​













In a prior version of this table, the code 10:608 was specified for the concept R wave.​





CID 3337 Hemodynamic Annotations​







Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​







Type:​

Extensible​









Version:​

20160314​









UID:​

1.2.840.10008.6.1.63​









Table CID 3337. Hemodynamic Annotations​



Coding Scheme​

Code Value​

Code Meaning​



SNOMED-RTID​UMLS Concept​

Designator​











Unique ID​

DCM​

109014​



35% of thermal/dye dilution CO​







DCM​

109015​



70% of thermal/dye dilution CO​







DCM​

109016​



A wave peak pressure​







DCM​

109017​



A wave pressure, average​







DCM​

109018​



Beat detected (accepted)​







DCM​

109019​



Beat detected (rejected)​







SCT​

314453003​

Average diastolic blood pressure​

F-00E22​

C1282163​

SCT​

314451001​

Minimum diastolic blood pressure​

F-00E1F​

C1282161​

SCT​

416190007​

End diastole​



R-FAB5C​

C1562146​

DCM​

109023​



End of expiration​







DCM​

109024​



End of inspiration​







DCM​

109070​



End of systole​







DCM​

109071​



Indicator mean transit time​







DCM​

109025​



Max dp/dt​







DCM​

109026​



Max neg dp/dt​







SCT​

6797001​



Mean blood pressure​



F-31150​

C0428886​

DCM​

109028​



Peak of thermal cardiac output bolus​





DCM​

109029​



Start of expiration​







DCM​

109030​



Start of inspiration​







DCM​

109031​



Start of thermal CO​







SCT​

314440001​

Average systolic blood pressure​

F-00E14​

C1282151​

SCT​

314439003​

Maximum systolic blood pressure​

F-00E11​

C1282150​

DCM​

109072​



Tau​







DCM​

109073​



V max myocardial​







DCM​

109034​



V wave peak pressure​







DCM​

109035​



V wave pressure, average​







DCM​

109036​



Valve close​







- Standard -​

Page 600​

DICOM PS3.16 2020a - Content Mapping Resource​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RTID​UMLS Concept​

Designator​







Unique ID​

DCM​

109037​

Valve open​





CID 3339 Electrophysiology Annotations​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20020904​







UID:​

1.2.840.10008.6.1.64​







Table CID 3339. Electrophysiology Annotations​

Coding Scheme Designator​

Code Value​



Code Meaning​

DCM​



109038​

Ablation off​



DCM​



109039​

Ablation on​



DCM​



109040​

HIS bundle wave​

DCM​



109041​

P wave​



DCM​



109042​

Q wave​



DCM​



109043​

R wave​



DCM​



109044​

S wave​



DCM​



109045​

Start of atrial contraction​

DCM​



109046​

Start of atrial contraction (subsequent)​

DCM​



109047​

Stimulation at rate 1 interval​

DCM​



109048​

Stimulation at rate 2 interval​

DCM​



109049​

Stimulation at rate 3 interval​

DCM​



109050​

Stimulation at rate 4 interval​

DCM​



109051​

T wave​



DCM​



109052​

V wave​



DCM​



109053​

V wave of next beat​

CID 3400 Procedure Log Titles​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20030327​







UID:​

1.2.840.10008.6.1.65​







Table CID 3400. Procedure Log Titles​



Coding Scheme Designator​

Code Value​



Code Meaning​

DCM​



121120​

Cath Lab Procedure Log​

CID 3401 Types of Log Notes​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20030327​







UID:​

1.2.840.10008.6.1.66​





- Standard -​

Соседние файлы в папке PS-2020a
Помощь Обратная связь Вопросы и предложения Пользовательское соглашение Политика конфиденциальности
