Table TID 5026. Parameters​

Parameter Name​

Parameter Usage​

$AnatomyGroup​

The concept name of the vascular anatomy​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 5026. OB-GYN Pelvic Vascular Ultrasound Measurement Group​

NL​

Rel with Parent​ VT​

Concept Name​

VM​

Req​ Condition​Value Set Constraint​

Type​

1​

CONTAINER​$AnatomyGroup​

1​

M​

2​

>​

HAS CONCEPT​ CODE​

EV (272741003, SCT,​

1​

MC​ IFF​

DCID 244 “Laterality”​

MOD​

"Laterality")​

anatomy​

has​

laterality​

3​

>​

HAS CONCEPT​ TEXT​

EV (112050, DCM,​

1​

U​

MOD​

"Anatomic Identifier")​

4​

>​

CONTAINS​

INCLUDE​

DTID 300 “Measurement”​ 1-n​

M​

$MeasType = DCID​

12119 “Vascular​

Ultrasound Property”​

$Derivation = DCID 3627​

“Measurement Type”​

5​

>>​

HAS CONCEPT​ CODE​

EV (125105, DCM,​

1​

U​

DCID 12118​

MOD​

"Measurement​

“Measurement​

Orientation")​

Orientation”​

6​

>>​

HAS​

NUM​

EV (125106, DCM,​

1​

U​

UNIT = EV (deg, UCUM,​

PROPERTIES​

"Doppler Angle")​

"deg")​

7​

>>​

HAS​

NUM​

EV (125107, DCM,​

1​

U​

UNIT = EV (cm, UCUM,​

PROPERTIES​

"Sample Volume Depth")​

"cm")​

Content Item Descriptions​

Row 1​

Specifies the anatomical context of the observations in the group.​

Row 3​

Differentiates between multiple structures such as the two umbilical arteries.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

NL​ Rel with​

VT​

Concept Name​

VM​Req​Condition​

Value Set Constraint​

Parent​

Type​

1​

CONTAINER​EV (125100, DCM,​

1​

M​

"Vascular Ultrasound​

Procedure Report")​

2​

>​

HAS OBS​ CODE​

EV (307152002, SCT,​

1​

U​

DCID 12102 “Temporal Periods Relating​

CONTEXT​

"Temporal periods​

to Procedure or Therapy”​

Relating to Procedure")​

3​

>​

HAS​

INCLUDE​

DTID 1204 “Language​ 1​

U​

CONCEPT​

of Content Item and​

MOD​

Descendants”​

4​

>​

HAS OBS​ INCLUDE​

DTID 1001​

1​

M​

CONTEXT​

“Observation Context”​

5​

>​

CONTAINS​INCLUDE​

DTID 5101 “Vascular​

1​

U​

Patient Characteristics”​

6​

>​

CONTAINS​CONTAINER​EV (111028, DCM,​

1​

U​

"Image Library")​

7​

>>​ CONTAINS​IMAGE​

1-n​ M​

8​

>​

CONTAINS​INCLUDE​

DTID 5102 “Vascular​

1​

U​

Procedure Summary​

Section”​

9​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (281231009, SCT,​

Ultrasound Section”​

"Blood Vessel of Head")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12105 “Intracranial​

Cerebral Vessels”​

10​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (281231009, SCT,​

Ultrasound Section”​

"Blood Vessel of Head")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12105 “Intracranial​

Cerebral Vessels”​

11​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (281231009, SCT,​

Ultrasound Section”​

"Blood Vessel of Head")​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 363​

NL​ Rel with​

VT​

Concept Name​

VM​Req​Condition​

Value Set Constraint​

Parent​

Type​

12​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (119568004, SCT,​

Ultrasound Section”​

"Artery of neck")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12104 “Extracranial​

Arteries”​

$AnatomyRatio = DCID 12123 “Carotid​

Ratios”​

13​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (119568004, SCT,​

Ultrasound Section”​

"Artery of neck")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12104 “Extracranial​

Arteries”​

$AnatomyRatio = DCID 12123 “Carotid​

Ratios”​

14​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (70791007, SCT,​

Ultrasound Section”​

"Artery of Lower Extremity")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12109 “Lower​

Extremity Arteries”​

15​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (70791007, SCT,​

Ultrasound Section”​

"Artery of Lower Extremity")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12109 “Lower​

Extremity Arteries”​

16​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (122774002, SCT,​

Ultrasound Section”​

"Vein of Lower Extremity")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12110 “Lower​

Extremity Veins”​

17​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (122774002, SCT,​

Ultrasound Section”​

"Vein of Lower Extremity")​

Page 364​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​ Rel with​

VT​

Concept Name​

VM​Req​Condition​

Value Set Constraint​

Parent​

Type​

18​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (75531005, SCT,​

Ultrasound Section”​

"Artery Of Upper Extremity")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12107 “Upper​

Extremity Arteries”​

19​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (75531005, SCT,​

Ultrasound Section”​

"Artery Of Upper Extremity")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12107 “Upper​

Extremity Arteries”​

20​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (122775001, SCT,​

Ultrasound Section”​

"Vein Of Upper Extremity")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12108 “Upper​

Extremity Veins”​

21​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (122775001, SCT,​

Ultrasound Section”​

"Vein Of Upper Extremity")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12108 “Upper​

Extremity Veins”​

22​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (303402001, SCT,​

Ultrasound Section”​

"Vascular Structure Of Kidney")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy=DCID12115“RenalVessels”​

$AnatomyRatio = DCID 12124 “Renal​

Ratios”​

23​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (303402001, SCT,​

Ultrasound Section”​

"Vascular Structure Of Kidney")​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 365​

NL​ Rel with​

VT​

Concept Name​

VM​Req​Condition​

Value Set Constraint​

Parent​

Type​

24​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (118634008, SCT,​

Ultrasound Section”​

"Artery of Abdomen")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12111 “Abdominal​

Arteries (Lateral)”​

25​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (118634008, SCT,​

Ultrasound Section”​

"Artery of Abdomen")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12111 “Abdominal​

Arteries (Lateral)”​

26​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (118634008, SCT,​

Ultrasound Section”​

"Artery of Abdomen")​

$SectionLaterality=EV(66459002,SCT,​

"Unilateral")​

$Anatomy = DCID 12112 “Abdominal​

Arteries (Unilateral)”​

27​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (84421000, SCT,​

Ultrasound Section”​

"Vein of Abdomen")​

$SectionLaterality = EV (7771000, SCT,​

"Left")​

$Anatomy = DCID 12113 “Abdominal​

Veins (Lateral)”​

28​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (84421000, SCT,​

Ultrasound Section”​

"Vein of Abdomen")​

$SectionLaterality=EV(24028007,SCT,​

"Right")​

$Anatomy = DCID 12113 “Abdominal​

Veins (Lateral)”​

29​

>​

CONTAINS​INCLUDE​

DTID 5103 “Vascular​

1​

U​

$SectionScope = DT (84421000, SCT,​

Ultrasound Section”​

"Vein of Abdomen")​

$SectionLaterality=EV(66459002,SCT,​

"Unilateral")​

$Anatomy = DCID 12114 “Abdominal​

Veins (Unilateral)”​

30​

>​

CONTAINS​INCLUDE​

DTID 5105 “Ultrasound​ 1​

U​

Graft Section”​

Content Item Descriptions​

Row 7​

No purpose of reference is specified.​

Page 366​

DICOM PS3.16 2020a - Content Mapping Resource​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

NL​ Rel with Parent​ VT​

Concept Name​

VM​

Req​ Condition​ Value Set​

Type​

Constraint​

1​

CONTAINER​EV (121118, DCM, "Patient​

1​

M​

Characteristics")​

2​

>​

CONTAINS​

NUM​

EV (121033, DCM, "Subject​

1​

U​

UNITS = DCID​

Age")​

7456 “Units of​

Measure for Age”​

3​

>​

CONTAINS​

CODE​

EV (121032, DCM, "Subject​

1​

U​

DCID 7455 “Sex”​

Sex")​

4​

>​

CONTAINS​

NUM​

EV (8867-4, LN, "Heart Rate")​

1​

U​

5​

>​

CONTAINS​

NUM​

EV (271649006, SCT, "Systolic​

1​

U​

Blood Pressure")​

6​

>​

CONTAINS​

NUM​

EV(271650006,SCT,"Diastolic​

1​

U​

Blood Pressure")​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 5102. Vascular Procedure Summary Section​

NL​ Rel with Parent​ VT​

Concept Name​

VM​

Req Type​Condition​ Value Set​

Constraint​

1​

CONTAINER​DT (121111, DCM,​

1​

M​

"Summary")​

2​

>​

CONTAINS​ TEXT​

DCID 12101 “Vascular​

1-n​

M​

Summary”​

Table TID 5103. Parameters​

Parameter Name​

Parameter Usage​

$SectionScope​

The concept name of the section heading modifier​

$SectionLaterality​

The laterality (if any) of the anatomy in this section heading​

$Anatomy​

The concept name of the vascular anatomy​

$AnatomyRatio​

The concept name of anatomy-coordinated ratio concepts​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 5103. Vascular Ultrasound Section​

NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​ValueSetConstraint​

Type​

1​

CONTAINER​DT (121070, DCM,​

1​

M​

"Findings")​

2​

>​

HAS CONCEPT​CODE​

EV (363698007, SCT,​

1​

M​

$SectionScope​

MOD​

"Finding Site")​

3​

>​

HAS CONCEPT​CODE​

EV (272741003, SCT,​

1​

M​

$SectionLaterality​

MOD​

"Laterality")​

4​

>​

CONTAINS​

INCLUDE​

DTID 5104 “Vascular​

1-n​

M​

$AnatomyGroup =​

Ultrasound Measurement​

$Anatomy​

Group”​

5​

>​

CONTAINS​

INCLUDE​

DTID 300 “Measurement”​

1-n​

U​

$Measurement =​

$AnatomyRatio​

Table TID 5104. Parameters​

Parameter Name​

Parameter Usage​

$AnatomyGroup​

The concept name of the vascular anatomy​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 5104. Vascular Ultrasound Measurement Group​

NL​

Rel with Parent​ VT​

Concept Name​

VM​

Req​Condition​ Value Set Constraint​

Type​

1​

CONTAINER​$AnatomyGroup​

1​

M​

2​

>​

HAS CONCEPT​ CODE​

EV (106233006, SCT,​

1​

U​

DCID 12116 “Vessel​

MOD​

"Topographical Modifier")​

Segment Modifiers”​

3​

>​

HAS CONCEPT​ CODE​

EV(125101,DCM,"Vessel​ 1-n​

U​

DCID 12117 “Vessel​

MOD​

Branch")​

Branch Modifiers”​

Page 368​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​Condition​ Value Set Constraint​

Type​

4​

>​

CONTAINS​

INCLUDE​

DTID 300 “Measurement”​ 1-n​

M​

$Measurement = DCID​

12119 “Vascular​

Ultrasound Property”​

$Derivation = DCID 3627​

“Measurement Type”​

5​

>>​

HAS CONCEPT​ CODE​

EV (272518008, SCT,​

1​

U​

DCID 12233 “Cardiac​

MOD​

"Cardiac Cycle Point")​

Phase”​

6​

>>​

HAS CONCEPT​ CODE​

EV (309602000, SCT,​

1​

U​

DT (24863003, SCT,​

MOD​

"Temporal period related​

"Post-prandial")​

to eating")​

7​

>>​

HAS CONCEPT​ CODE​

EV (125105, DCM,​

1​

U​

DCID12118“Measurement​

MOD​

"Measurement​

Orientation”​

Orientation")​

8​

>>​

HAS​

NUM​

EV (125106, DCM,​

1​

U​

UNIT = EV (deg, UCUM,​

PROPERTIES​

"Doppler Angle")​

"degrees")​

9​

>>​

HAS​

NUM​

EV (125107, DCM,​

1​

U​

UNIT = EV (cm, UCUM,​

PROPERTIES​

"Sample Volume Depth")​

"cm")​

Content Item Descriptions​

Row 1​

Specifies the anatomic context of the observations in the group.​

Row 2​

Details the anatomical location, e.g., proximal, middle, or distal​

Row 3​

The particular vessel branch, such as the inferior, medial or lateral​

Row 5​

Cardiac phase (systolic, diastolic), especially for aorta measurements​

Row 6​

Eating phase, especially for mesenteric and celiac measurements​

TID 5105 Ultrasound Graft Section​

This Template is a container of measurements on a vascular graft.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 5105. Ultrasound Graft Section​

NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​ Value Set Constraint​

Type​

1​

CONTAINER​DT (121070, DCM,​

1​

M​

"Findings")​

2​

>​

HAS CONCEPT​ CODE​

EV (363698007, SCT,​

1​

M​

DT (312288001, SCT,​

MOD​

"Finding Site")​

"Vascular Graft")​

3​

>​

HAS CONCEPT​ CODE​

EV (272741003, SCT,​

1​

U​

DCID 244 “Laterality”​

MOD​

"Laterality")​

4​

>​

HAS CONCEPT​ CODE​

DT (128949003, SCT,​

1​

M​

BCID 12103 “Vascular​

MOD​

"Proximal anastomosis")​

Ultrasound Anatomic​

Location”​

5​

>​

HAS CONCEPT​ CODE​

DT (128948006, SCT,​

1​

M​

BCID 12103 “Vascular​

MOD​

"Distal Anastomosis")​

Ultrasound Anatomic​

Location”​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 369​

NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​ Value Set Constraint​

Type​

6​

>​

HAS CONCEPT​ CODE​

DT (125102, DCM, "Graft​

1​

U​

MOD​

Type")​

7​

>​

CONTAINS​

INCLUDE​

DTID 300 “Measurement”​ 1-n​

M​

$Measurement = DCID​

12119 “Vascular​

Ultrasound Property”​

Content Item Descriptions​

Proximal anastomosis​

The proximal location of the graft​

Distal anastomosis​

The distal location of the graft​

Graft type​

The type of graft, e.g., "in situ", "prosthetic", "autogenous"​

Type:​

Extensible​

Order:​

Significant​

Root:​

Yes​

NL​

Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

1​

CONTAINER​EV (125200, DCM,​

1​

M​

Root node​

"Adult​

Echocardiography​

Procedure Report")​

2​

>​

HAS​

INCLUDE​

DTID 1204 “Language​ 1​

U​

CONCEPT​

of Content Item and​

MOD​

Descendants”​

3​

>​

HAS OBS​

INCLUDE​

DTID 1001​

1​

M​

CONTEXT​

“Observation Context”​

4​

>​

CONTAINS​ CONTAINER​DT (55111-9, LN,​

1​

U​

"Current Procedure​

Descriptions")​

5​

>>​

CONTAINS​ CODE​

DT (125203, DCM,​

1-n​

M​

BCID 12001 “Ultrasound Protocol​

"Acquisition Protocol")​

Types”​

6​

>​

CONTAINS​ INCLUDE​

DTID 5201​

1​

U​

“Echocardiography​

PatientCharacteristics”​

7​

>​

CONTAINS​ CONTAINER​EV (111028, DCM,​

1​

U​

"Image Library")​

8​

>>​

CONTAINS​ IMAGE​

1-n​

M​

Page 370​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​

Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

9​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (87878005,​

Section”​

SCT, "Left Ventricle")​

$MeasType = DCID 12200​

“Echocardiography Left Ventricle”​

10​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (53085002,​

Section”​

SCT, "Right Ventricle")​

$MeasType = DCID 12204​

“Echocardiography Right Ventricle”​

11​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (82471001,​

Section”​

SCT, "Left Atrium")​

$MeasType = DCID 12205​

“Echocardiography Left Atrium”​

12​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (73829009,​

Section”​

SCT, "Right Atrium")​

$MeasType = DCID 12206​

“Echocardiography Right Atrium”​

13​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (34202007,​

Section”​

SCT, "Aortic Valve")​

$MeasType = DCID 12211​

“Echocardiography Aortic Valve”​

14​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (91134007,​

Section”​

SCT, "Mitral Valve")​

$MeasType = DCID 12207​

“Echocardiography Mitral Valve”​

15​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (39057004,​

Section”​

SCT, "Pulmonic Valve")​

$MeasType = DCID 12209​

“Echocardiography Pulmonic Valve”​

16​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (46030003,​

Section”​

SCT, "Tricuspid Valve")​

$MeasType = DCID 12208​

“Echocardiography Tricuspid Valve”​

17​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (15825003,​

Section”​

SCT, "Aorta")​

$MeasType = DCID 12212​

“Echocardiography Aorta”​

18​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (81040000,​

Section”​

SCT, "Pulmonary artery")​

$MeasType = DCID 12210​

“EchocardiographyPulmonaryArtery”​

19​

>​

CONTAINS​ INCLUDE​

DTID 5202 “Echo​

1​

U​

$SectionSubject = EV (35532006,​

Section”​

SCT, "Vena Cava")​
