Input-Output (I/O)

Packages

java.io

Use: J2SE (since version 1.0)

Description

The main goal of the Java I/O API is to allow developers to use streams. Streams provide basic input-output capabilities in Java. If you want to write to a file, use a stream; if you want to read from standard input, use a stream. If you want to write across a network—well, you get the idea.

The java.io package contains four general types of stream, which are based on four abstract classes. These classes provide functionality based on stream direction (input or output) and level whether the stream information is based on bytes or characters.

Table 6-3. Stream types in the java.io package

All other streams in Java subclass one of these four classes, and extend the functionality of the class by adding a specific capability. For example, the FileWriter is a type of Writer (output, writes characters) and it adds the ability to write characters to a file on disk. The DataInputStream is a kind of InputStream (input, reads bytes) and it also allows developers to read different data types, such as an int, float, or boolean value.

How do you create a stream with combinations of abilities in Java? You “chain” them together, using the concept of a filter stream. You can attach filter streams to other streams by passing the target stream into the filter's constructor. The filter can then add its own functionality to the associated stream. For example, you could read lines of text from the standard input stream by using these lines of code:

Example 6.2 Streams in Java

BufferedReader readIn =

new BufferedReader(new InputStreamReader(System.in)); String textLine = readIn.readLine();

In this example, input ultimately comes from System.in (keyboard input) in the form of bytes. By adding an InputStreamReader, you can use the passed bytes to make Java language characters. Finally, the

BufferedReader places the characters from the InputStreamReader into a buffer. The BufferedReader can

detect when the end of line is reached, and release the buffered characters as a String.

There aren’t a lot of stream classes in the java.io package. However, since you can mix and match filter streams, you ultimately have much more functionality available than you might think. You can think of Java I/O as a pipeline. When you write code, you attach different I/O objects, or “pipes,” to each other. With each section of pipe added, you modify the flow through the pipeline.

Pattern Use

It’s evident that a lot of I/O programming involves stream chaining. To support this capability, the API relies heavily on a variation of the structural pattern, the Decorator (see page 166).

Each of the four abstract classes— InputStream, OutputStream, Reader and Writer —acts as the base for a decorator chain. The I/O classes that support decorator behavior have one or more constructors that accept an argument of another I/O class to chain. java.io contains the following categories of I/O classes:

Base I/O classes (also called node streams) – These classes provide endpoints of communication; they are actually attached to some end location. For example, a FileReader is not a decorator because it is directly connected to a file.

195

Paired streams – At first glance, these streams might appear to be Decorators, since they have the ability to be attached to another stream. However, the classes are actually designed to work in complementary pairs— the output of one feeds the input of another. You can think of these classes as base I/O classes; they can be decorated themselves, but their true function is to establish a communication channel to another stream.

PipedWriterFilter streams – The filter streams use the Decorator pattern to support chaining. The filter classes use the following rules to manage decorator behavior:

A filter decorates a class using a constructor that accepts one of the four base I/O classes: InputStream,

OutputStream, Reader, or Writer.

The filter class usually decorates classes of the same type. This means that an InputStream that is also a filter will decorate another InputStream, for example. The important exceptions to this rule are the InputStreamReader and OutputStreamWriter, which translate between bytes and characters.

196
