.pdfABEND (macro), result in log, PSW
Kirill Melentyev
Program Status Word (PSW)
... is an IBM System/360 architecture and successors control register which performs the function of a Status register and Program counter in other architectures, and more.
R – enable program event recording (PER)
T – enable dynamic address translation (virtual storage) I – enable I/O interrupts
E – enable external interrupts
Key – define storage protection key
M – enable machine checks
W – wait state
P – problem state (0 = supervisor state)
AS – address space (00 = primary space mode, 01 = secondary space mode, 10 = access register mode, 11 = home space mode)
CC – condition code
Program mask
–Bit 20: enable fixed-point overflow exception
–Bit 21: enable decimal overflow exception
–Bit 22: enable hex floating-point exponent underflow exception
–Bit 23: enable hex floating-point significance exception
Instruction address
– It is stepped by the length of the current instruction
Abend
An abend is an abnormal end or termination of a computer program because of some problem with how it is running
ABEND macro
The ABEND macro is used to initiate error processing for a task. ABEND can request a full or tailored dump of virtual storage areas and control blocks pertaining to the tasks being abnormally terminated, and can specify that the entire job step is to be abnormally terminated.
Parameters
●completion code (can be user or system S0C4)
●,DUMP (SYSUDUMP)
●,,STEP
●,,,code type (USER/SYSTEM)
●,REASON=reason code
●,DUMP,DUMPOPT=parm list addr (SNAP)
●,DUMP,DUMPOPX=parm list addr (SNAPX)
ABEND (5),,STEP
ABEND X'0C4',DUMP,,SYSTEM
Symptom Dump
… is a system message, either message IEA995I or a numberless message, which provides some basic diagnostic information for diagnosing an abend
